6-84

Component Definition and Maintenance

7000A-UM150F-EN-P –June 2013

7000 “A” Frame

Drive Control Boards (cont.)

Drive Control Board
(Machine)

Fiber Optic
Interface
Boards

Drive Control Board
(Line)

Customer Interface
Board

Figure 6.65 – DCB/CIB Board Replacement (Mounting Plate Accessible)
