Rockwell Automation 7000A PowerFlex Medium Voltage Drive (A-Frame) - Classic Control User Manual
Page 222
4-48
Commissioning
7000A-UM150F-EN-P – June 2013
7000 “A” Frame
Inverter Modules
Rectifier Modules
Transient
Suppression
Network Fuses
Transient
Suppression
Network
Voltage Sensing Boards
Isolated
Gate Drive
Power
Supplies
(IGDPS)
Inverter Modules
Rectifier Modules
Transient
Suppression
Network Fuses
Transient
Suppression
Network
Voltage Sensing Boards
Isolated
Gate Drive
Power
Supplies
(IGDPS)
Figure 4.18 – Converter Cabinet Components (6600V version)
