Component Definition and Maintenance 6-79

7000 “A” Frame

7000A-UM150F-EN-P –June 2013


P6-SCBM

PIN#

LABEL

DESCRIPTION ONLY

1

+LEMPWR (+24V,1A)

+24V,1A/com2

2

LCOMM (com2)

0V/com2

3

–LEMPWR (-24V,1A)

-24V,1A/com2

4

+15V_PWR (+15V,1A)

+15V,1A/com1

5

ACOMM (com1)

0V/com1

6

–15V_PWR (-15V,1A)

-15V,1A/com1

7

+5V_PWR (+5V,10A)

+5V,10A/com1

8

DGND (com1)

0V/com1

9

+15V_ENC (+15V,1A)

+15V,1A/com3

10

ENC_COMM (com3)

0V/com3

11

DGND (com1)

0V/com1

P7-CIB

PIN#

LABEL

DESCRIPTION ONLY

1

XIO_PWR (+24V,3A)

+24V,3A/com5

2

XIOCOMM (com5)

0V/com5

3

+15V_PWR (+15V,1A)

+15V,1A/com1

4

ACOMM (com1)

0V/com1

5

–15V_PWR (-15V,1A)

-15V,1A/com1

6

+5V_PWR (+5V,10A)

+5V,10A/com1

7

DGND (com1)

0V/com1

8

+SCNPWR (+12V,1A)

+12V,1A/com1

9

SCNCOMM (com1)

0V/com1

10

DGND (com1)

0V/com1


Replacement Procedure for DC/DC Power Supply

(Refer to Figure 6.63)

1. With the drive energized, check to see if the indicator light is ON or

OFF. If it is OFF, replacement is necessary. (View 1)

2. De-energize the drive, isolate and lock out the control power, and

remove all wire connections from the unit. (View 1)

3. Remove quantity of (4) M6 (H.H.T.R.S.) that will allow the DC/DC

Power Supply Assembly to be removed from the Low Voltage Panel.
(View 1)

4. Remove quantity of (4) M4 (P.H.M.S.) and Nylon Shoulder

Washers from the back of the Mounting Plate. ( View 2)

5. Replace old DC/DC Power Supply with the new one.

NOTE: Make sure the Black Insulation is between the DC/DC
Power Supply and the Mounting Plate. Repeat Steps 4, 3, 2, 1
in this order to replace unit. (View 2)
