1-14

Overview of Drive

7000A-UM150F-EN-P – June 2013

7000 “A” Frame

Simplified Electrical Drawings – 3300/4160V with 6-pulse Rectifier


REMOTE
ISTX

2U (X1)

2V (X2)

2W (X3)

1U

1V

1W

SCR’s

LINE CONVERTER

DC LINK

L+

M+

SGCT’s

MACHINE CONVERTER

U (T1)

V (T2)

W (T3)

L-

M-

3300/4160 Volt – 6-pulse Rectifier, Base Drive with Connection for Remote Isolation Transformer



SCR’s

LINE CONVERTER

DC LINK

L+

M+

SGCT’s

MACHINE CONVERTER

U (T1)

V (T2)

W (T3)

L-

M-

INTEGRAL
ISTX

2U (X1)

2V (X2)

2W (X3)

1U

1V

1W

3300/4160 Volt – 6-pulse Rectifier, Base Drive with Integral Isolation Transformer



LR

L1

L2

L3

SCR’s

LINE CONVERTER

DC LINK

L+

M+

SGCT’s

MACHINE CONVERTER

U (T1)

V (T2)

W (T3)

L-

M-

3300/4160 Volt – 6-pulse Rectifier, Base Drive with Integral Line Reactor and Input Starter

(Configurations without Integral Input Starter are available)
