Component definition and maintenance, Chapter – Rockwell Automation 7000A PowerFlex Medium Voltage Drive (A-Frame) - Classic Control User Manual
Page 305
Chapter
6
7000 “A” Frame
7000A-UM150F-EN-P – June 2013
Component Definition and Maintenance
Cabling Cabinet Components
Low Voltage Wireway
Control Power
Transformer Fuses
Motor Cable Terminations
Current Transformer
Fan Control Power Transformer
Isolation Transformer
Secondary Terminations
Hall Effect Sensor
Current Transformer
Hall Effect Sensor
Low Voltage Wireway
Control Power
Transformer Fuses
Motor Cable Terminations
Current Transformer
Fan Control Power Transformer
Isolation Transformer
Secondary Terminations
Hall Effect Sensor
Current Transformer
Hall Effect Sensor
Figure 6.1 – Cabling Cabinet for Base Drive
