5Ć14
5.8.4 Adding the PC3000 Processor Card's Address to
the CONFIG.SYS File
You may need to edit the CONFIG.SYS file to add the PC3000
Processor card's memory address. To edit the CONFIG.SYS file,
follow these steps:
Step 1.
Using a text editor, open the CONFIG.SYS file located in
the root of the boot drive.
Step 2. Search for the line containing: EMM386.SYS
Step 3. Use this table to determine your next step:
БББББ
БББББ
If you: ББББББББББББББББ
ББББББББББББББББ
Do the following:
БББББ
Б БББ Б
Б БББ Б
Б БББ Б
Б БББ Б
Б БББ Б
Б БББ Б
Б БББ Б
Б БББ Б
Б БББ Б
Б БББ Б
БББББ
find the line
containing:
EMM386.SYS
ББББББББББББББББ
Б ББББББББББББББ Б
Б ББББББББББББББ Б
Б ББББББББББББББ Б
Б ББББББББББББББ Б
Б ББББББББББББББ Б
Б ББББББББББББББ Б
Б ББББББББББББББ Б
Б ББББББББББББББ Б
Б ББББББББББББББ Б
Б ББББББББББББББ Б
ББББББББББББББББ
a) Append the following to the EMM386.SYS
statement: X=MEM1ĆMEM2
Where: MEM1 = the starting address of the next
PC3000 Processor card
MEM2 = the ending address of the next
PC3000 Processor card
Example
:
EMM386.SYS X=C800-C9FF X=CA00-CBFF
NOTE: Although Windows 95 displays the address range in
five digits, you must enter the address as four digits.
Do not enter the fifth digit in the CONFIG.SYS file.
b) Add a comment on a separate line to this address that
documents the serial number of the Processor card.
For example:
REM X = CA00-CBFF //(serial number)
c) Save and close the CONFIG.SYS file.
d) Reboot the computer into Windows 95.
БББББ
БББББ
do not find the
line
ББББББББББББББББ
ББББББББББББББББ
a) Close the CONFIG.SYS file.
b) Reboot the computer into Windows 95.
5.9 What to Do Next
Finish installing your other system components. For more information
about monitoring the PC3000, see chapter 20.
