4Ć1

4.0 DESIGNING CONTROL

SYSTEMS THAT USE THE

ALLENĆBRADLEY REMOTE

I/O LINK

You can use the AutoMax PC3000 to scan remote racks on the

AllenĆBradley Remote I/O Network.

For information about:

See this section:

Components of an AllenĆBradley Remote I/O System

4.1

Dividing I/O into Racks

4.2

Designing a Remote I/O Link

4.3

Determining Remote I/O Scan Times

4.4

Optimizing System Performance

4.5

AĆB Equipment Installation Considerations

4.6

What to Do Next

4.7

For further information, see these AllenĆBradley publications:
D Rockwell Automation Industrial Automation Wiring and

Grounding Guidelines, publication 1770Ć4.1

D Rockwell Automation Safety Guidelines for the Application,

Installation, and Maintenance of Solid State Controls, publication

SGIĆ1.1

Also refer to IEEE standard 518Ć1982.
