16Ć2
Table 16.1 Ć Setting the Remote I/O Data Communication Rate
To use this communication rate: Write this value into the variĆ
able associated with the Data
Rate (register 769):
57.6 Kbps
0
115.2 Kbps
1
230.4 Kbps
2
Important: The data communication rate must be set before you
enable the scanner module to start scanning the remote I/O racks.
Should you ever need to change the data communication rate,
follow the procedure in section 16.4.
16.2
Specifying the Remote Racks That Will Be
Scanned
Within the initialization program, you must specify the remote I/O
racks that you want the PC3000 scanner to scan by setting each
rack's Rack Enable bit, because on powerĆup all racks are disabled.
Set the Rack Enable bit for all configured remote I/O racks used in
your system.
To enable a rack, set bit 0 of the variable corresponding to the Rack
Enable register to on (1).
Table 16.2 Ć Listing of the Remote Rack Enable Registers
To enable
this rack:
Set bit 0 of
this register
to on (1):
To enable
this rack:
Set bit 0 of
this register
to on (1):
Rack 0
512
Rack 20
640
Rack 1
520
Rack 21
648
Rack 2
528
Rack 22
656
Rack 3
536
Rack 23
664
Rack 4
544
Rack 24
672
Rack 5
552
Rack 25
680
Rack 6
560
Rack 26
688
Rack 7
568
Rack 27
696
Rack 10
576
Rack 30
704
Rack 11
584
Rack 31
712
Rack 12
592
Rack 32
720
Rack 13
600
Rack 33
728
Rack 14
608
Rack 34
736
Rack 15
616
Rack 35
744
Rack 16
624
Rack 36
752
Rack 17
632
Rack 37
760
If you want to prevent a rack from being scanned, make sure that bit
0 of the rack's Rack Enable Register is off (0).
