20Ć1
20.0 MAINTAINING THE AutoMax
PC3000
Routine maintenance of the AutoMax PC3000 includes replacing:
D the battery on the AutoMax PC3000 Processor card
D the air filter for the Industrial AutoMax PC3000 chassis
БББББББББББББ
БББББББББББББ
For information about:
ББББББББ
ББББББББ
See this section:
БББББББББББББ
БББББББББББББ
Handling the Cards
ББББББББ
ББББББББ
20.1
БББББББББББББ
БББББББББББББ
Replacing the Battery on the AutoMax PC3000
Processor Card ББББББББ
ББББББББ
20.2
БББББББББББББ
БББББББББББББ
Replacing the AutoMax PC3000 Processor Card
ББББББББ
ББББББББ
20.3
БББББББББББББ
БББББББББББББ
Removing the old AutoMax PC3000 Processor
Card from the Device Manager
ББББББББ
ББББББББ
20.4
БББББББББББББ
БББББББББББББ
Replacing the AutoMax PC3000 Serial Card ББББББББ
ББББББББ
20.5
БББББББББББББ
Б БББББББББББ Б
БББББББББББББ
Replacing the AutoMax PC3000
Packaged Version
ББББББББ
Б ББББББ Б
ББББББББ
20.6
БББББББББББББ
БББББББББББББ
Replacing the Filter for the AutoMax PC3000
Packaged Version ББББББББ
ББББББББ
20.7
БББББББББББББ
БББББББББББББ
What to Do Next
ББББББББ
ББББББББ
20.8
20.1 Handling the Cards
CAUTION: The printed circuit boards are staticĆsensitive. You should wear an
antiĆstatic wrist band (user supplied) while installing the AutoMax PC3000 Processor or
Serial cards. Avoid touching the cards components, connectors, or leads. Failure to
observe this precaution could result in damage to or destruction of the equipment.
When handling the AutoMax PC3000 Processor or Serial card, hold
the card only at its edges.
20.2 Replacing the Battery on the AutoMax
PC3000 Processor Card
The battery retains the PC3000 memory for about 186 days in the
event of a power failure. Replace the battery only with Reliance
Electric M/N 57C385.
The super capacitor provides a minimum of ten minutes (a
maximum of ten hours) of backup power after the
BATTERYSTATUS4@ variable goes false and power is removed
from the rack. You need to replace the battery before backĆup power
fails to avoid reĆloading the operating system and application tasks.
When replacing the battery, you must:
D remove the AutoMax PC3000 Processor card
D replace the battery
D reĆinstall the AutoMax PC3000 Processor card
