GĆ6
1Ćslot Rack Addressing Configuration Example
(Racks 20 and 21)
SLC
Chassis
Physical
Slot
Number of
Inputs/Outputs
Per Physical
Slot
Logical I/O
Group
Scanner Register Location
Input Register Output Register
0 8 bits in 0 384
(low byte)
1 8 bits out 1 129
(low byte)
2 16 bits in 2 386
3 16Ćbits out 3 131
4 16Ćbits out 4 132
5 16Ćbits in 5 389
6 32Ćbits out * 6 134 & 135
7 32Ćbits in * 7 390 & 391
8 0
9 1
10 2
11 3
12 4
13 5
14 6
15 7
*Even registers are the low word and odd registers the high word.
Rack 20
Rack 21
