DĆ4
Input Image Table
Register:
Bit:
Function:
Access:
Rack 20
384Ć391
Rack 20 Input image table
read
Rack 21
392Ć399
Rack 21 Input image table
read
Rack 22
400Ć407
Rack 22 Input image table
read
Rack 23
408Ć415
Rack 23 Input image table
read
Rack 24
416Ć423
Rack 24 Input image table
read
Rack 25
424Ć431
Rack 25 Input image table
read
Rack 26
432Ć439
Rack 26 Input image table
read
Rack 27
440Ć447
Rack 27 Input image table
read
Rack 30
448Ć455
Rack 30 Input image table
read
Rack 31
456Ć463
Rack 31 Input image table
read
Rack 32
464Ć471
Rack 32 Input image table
read
Rack 33
472Ć479
Rack 33 Input image table
read
Rack 34
480Ć487
Rack 34 Input image table
read
Rack 35
488Ć495
Rack 35 Input image table
read
Rack 36
496Ć503
Rack 36 Input image table
read
Rack 37
504Ć511
Rack 37 Input image table
read
Remote Rack Status (8 words per rack)
Register:
Bit:
Function:
Access:
Rack 0
512
0
Rack 0 Enable.
To enable the rack, set this bit
to 1. To disable the rack, set
this bit to 0.
read/write
513
Rack 0 Rack Status
A value of 0 means rack 0 is
not being updated.
A value of 1 means rack 0 is
OK in RUN mode.
A value of 2 means rack 0 is
OK and not in RUN mode.
A value of 3 means rack 0 has
an error.
read
514
Module group ending rack 0
A value of 0 means rack 0
ends at I/O group 1.
A value of 1 means rack 0
ends at I/O group 3.
A value of 2 means rack 0
ends at I/O group 5.
A value of 3 means rack 0
ends at I/O group 7.
read
515
Rack 0 timeouts.
After 255 timeouts, the
counter restarts at 0.
read
