DĆ3
Output Image Table
Register: Bit: Function: Access:
Rack 27 184Ć191 Rack 27 Output image table read/write
Rack 30 192Ć199 Rack 30 Output image table read/write
Rack 31 200Ć207 Rack 31 Output image table read/write
Rack 32 208Ć215 Rack 32 Output image table read/write
Rack 33 216Ć223 Rack 33 Output image table read/write
Rack 34 224Ć231 Rack 34 Output image table read/write
Rack 35 232Ć239 Rack 35 Output image table read/write
Rack 36 240Ć247 Rack 36 Output image table read/write
Rack 37 248Ć255 Rack 37 Output image table read/write
Input Image Table
Register: Bit: Function: Access:
Rack 0 256 Rack 0, I/O group 0: Input
image table
read
257 Rack 0, I/O group 1: Input
image table
read
258 Rack 0, I/O group 2: Input
image table
read
259 Rack 0, I/O group 3: Input
image table
read
260 Rack 0, I/O group 4: Input
image table
read
261 Rack 0, I/O group 5: Input
image table
read
262 Rack 0, I/O group 6: Input
image table
read
263 Rack 0, I/O group 7: Input
image table
read
Rack 1 264Ć271 Rack 1 Input image table read
Rack 2 272Ć279 Rack 2 Input image table read
Rack 3 280Ć287 Rack 3 Input image table read
Rack 4 288Ć295 Rack 4 Input image table read
Rack 5 296Ć303 Rack 5 Input image table read
Rack 6 304Ć311 Rack 6 Input image table read
Rack 7 312Ć319 Rack 7 Input image table read
Rack 10 320Ć327 Rack 10 Input image table read
Rack 11 328Ć335 Rack 11 Input image table read
Rack 12 336Ć343 Rack 12 Input image table read
Rack 13 344Ć351 Rack 13 Input image table read
Rack 14 352Ć359 Rack 14 Input image table read
Rack 15 360Ć367 Rack 15 Input image table read
Rack 16 368Ć375 Rack 16 Input image table read
Rack 17 376Ć383 Rack 17 Input image table read
