2Ć6
2.3 Finding the Information You Need When
You Are New to AutoMax
If you are a new user of the AutoMax product family, make sure to
see these chapters in addition to the AutoMax PC3000 specific
chapters:
D chapter 3 Designing an AutoMax DCSĆNET Network
D chapter 7 Installing the AutoMax Coaxial DCSĆNET Network
D chapter 8 Installing an AutoMax FiberĆOptic DCSĆNET Network
D chapter 15 AutoMax Programming Basics
D chapter 21 Maintaining the DCSĆNET Network
D Appendix C Cable Reference
D Appendix D Register Assignment Map
D Appendix F Using the Sample AutoMax Configurations and Programs
2.4 Finding the Information You Need When
You Are New to AllenĆBradley Remote I/O
If you are a new user of AĆB Remote I/O, make sure to see these
chapters in addition to the AutoMax PC3000 specific chapters:
D chapter 4 Designing Control Systems That Use the AllenĆBradley
Remote I/O Link
D chapter 9 Connecting an AllenĆBradley Remote I/O Link
D chapter 13 Configuring the AutoMax AllenĆBradley PC3000 Scanner
D chapter 14 Configuring and Programming Block Data Transfers to
AĆB I/O Modules
D chapter 16 Initializing the AutoMax PC3000 AĆB Remote I/O Scanner
D Appendix C Cable Reference
D Appendix D Register Assignment Map
D Appendix G Examples of Remote I/O Programs
2.5 Overview of the Tasks Required to
Configure and Run the Remote I/O
Scanner Interface
Developing a good system design is important to any control
system. See chapter 4, Designing Control Systems That Use the
AllenĆBradley Remote I/O Link" for information to consider while
designing a control system using AllenĆBradley remote I/O. Included
is some basic information about how AllenĆBradley I/O is segmented
into logical units, such as I/O racks and I/O groups. An I/O rack is
different than an I/O chassis. An I/O chassis is the physical housing
of the I/O modules; whereas, an I/O rack is an addressing unit that
equals 128 input bits and 128 output bits.
