17Ć1
17.0 EXCHANGING DATA WITH
AN AutoMax PC3000 OVER
THE ISA BUS
You can use the ISA bus to exchange data between an internal
PC3000 and the PC's microprocessor. This section provides a brief
explanation of these registers.
БББББББББББББББ
БББББББББББББББ
For this information:
ББББББ
ББББББ
See section:
БББББББББББББББ
БББББББББББББББ
About the Register Organization of the AutoMax PC3000
Application Interface
ББББББ
ББББББ
17.1
БББББББББББББББ
БББББББББББББББ
Using the Volatile Variables
ББББББ
ББББББ
17.2
БББББББББББББББ
БББББББББББББББ
Using the NonĆVolatile Variables
ББББББ
ББББББ
17.3
БББББББББББББББ
Using the System Information Variables
ББББББ
17.4
БББББББББББББББ
БББББББББББББББ
What to Do Next
ББББББ
ББББББ
17.5
17.1
About the Register Organization of the
AutoMax PC3000 Application Interface
The PC3000 Application Interface contains registers you can use to
exchange information over the ISA backplane between applications
running on the PC3000 and applications running on the PC's
microprocessor. The Application Interface contains both volatile and
nonĆvolatile registers. You can attach a variable to a whole register
or to individual bits within a register.
When creating programs that use variables in these registers, keep
in mind the addressing differences that exist between the AutoMax
PC3000 and the Intel
microprocessor in a PC. Real variables in the
AutoMax PC3000 are in the Motorola
format. You can use the
BASIC function CONVERT% to convert them into the Intel or IEEE
format. See the AutoMax Enhanced BASIC Language instruction
manual, JĆ3675, for more information.
17.2
Using the Volatile Variables
Use registers 0Ć999 of the PC3000 Application Interface to store
volatile data. Variables do not retain their value through power
cycles and Stop All conditions.
17.3
Using the NonĆVolatile Variables
Use registers 1000Ć1999 of the PC3000 Application Interface to store
nonĆvolatile data. Variables retain their value through Stop All
conditions and power cycles.
