DĆ5
Remote Rack Status (8 words per rack)
Register:
Bit:
Function:
Access:
Rack 0
516
Rack 0 CRC errors
After 255 timeouts, the
counter restarts at 0.
read
517
Rack 0 failures
After 255 timeouts, the
counter restarts at 0.
read
518
Rack 0 protocol errors
After 255 timeouts, the
counter restarts at 0.
read
519
Rack 0 block transfer protocol
errors
After 255 timeouts, the
counter restarts at 0.
read
Rack 1
520Ć527
Rack 1 Rack Status
and Control
See
layout for
rack 0.
Rack 2
528Ć535
Rack 2 Rack Status
and Control
See
layout for
rack 0.
Rack 3
536Ć543
Rack 3 Rack Status
and Control
See
layout for
rack 0.
Rack 4
544Ć551
Rack 4 Rack Status
and Control
See
layout for
rack 0.
Rack 5
552Ć559
Rack 5 Rack Status
and Control
See
layout for
rack 0.
Rack 6
560Ć567
Rack 6 Rack Status
and Control
See
layout for
rack 0.
Rack 7
568Ć575
Rack 7 Rack Status
and Control
See
layout for
rack 0.
Rack 10
576Ć583
Rack 10 Rack Status
and Control
See
layout for
rack 0.
Rack 11
584Ć591
Rack 11 Rack Status
and Control
See
layout for
rack 0.
Rack 12
592Ć599
Rack 12 Rack Status
and Control
See
layout for
rack 0.
Rack 13
600Ć607
Rack 13 Rack Status
adn Control
See
layout for
rack 0.
Rack 14
608Ć615
Rack 14 Rack Status
and Control
See
layout for
rack 0.
