13Ć4
For this information:
See:
listing of the registers associated with
the remote rack status and control
appendix D, Register Assignment
Map"
how to clear and correct rack errors
chapter 16, Initializing the AutoMax
PC3000 AĆB Remote I/O Scanner"
To assign variable names to the remote rack status and control
registers, use the scanner's Variable Configurator form. When you
choose the Remote Rack Status and Control Table view, you see a
form similar to the one shown in Figure 13.3.
Figure 13.3 Ć Remote Rack Status and Control Table View
All remote rack status and control registers are read only, except the
rack enable register.
For information about enabling a remote rack and monitoring its
status, see chapter 16, Initializing the AutoMax PC3000 AĆB Remote
I/O Scanner."
13.3
Configuring the I/O Scanner by Assigning
Variable Names to the Scanner Setup and
Status Registers
Registers within the scanner, which are 16Ćbit words, have been
assigned to these functions:
D controlling scanning and the scan mode
D defining the remote I/O communication rate
D monitoring the remote I/O link status
D storing the module ID
See Appendix D, Register Assignment Map" for a complete listing
of the registers associated with the scanner setup and status.
