18.4
Ensuring Network Integrity
WARNING
THE AutoMax NETWORK IS DESIGNED TO CONTINUE OPERATING IF ONE OR
MORE DROPS ON THE NETWORK FAILS OR IS TAKEN OFFLINE. IF CERTAIN
DATA MUST BE TRANSFERRED RELIABLY TO ENSURE SAFE OPERATION, THE
USER MUST ADD SOFTWARE HANDSHAKING IN THE APPLICATION PROGRAM
THAT WILL DETECT LOSS OF COMMUNICATION. FAILURE TO OBSERVE THIS
PRECAUTION MAY RESULT IN BODILY INJURY.
WARNING
THE USER MUST PROVIDE AN EXTERNAL, HARDWIRED EMERGENCY STOP
CIRCUIT OUTSIDE OF THE CONTROLLER CIRCUITRY. THIS CIRCUIT MUST
DISABLE THE SYSTEM IN CASE OF IMPROPER OPERATION. UNCONTROLLED
MACHINE OPERATION MAY RESULT IF THIS PROCEDURE IS NOT FOLLOWED.
FAILURE TO OBSERVE THIS PRECAUTION COULD RESULT IN BODILY INJURY.
In the event of a network failure, i.e., a drop becomes unable to
communicate with the master for any reason, controls must be in
place to ensure the system reacts in a predictable, controlled
manner. Each Network interface contains bits that indicate
communication status. These bits must be used in the application
program to generate faults indicating communication failure.
Application programs in the other racks determine how the system
will react to a particular drop going offline. The application program
must ensure that properly functioning units on the network can
continue to run with the states of I/O and process variables
controlled in a predictable and safe manner.
If the network is installed correctly, the drops will communicate with
essentially no errors at all. It is a normal occurrence in a system like
this to periodically have an error, but the frequency should be very
low. You may notice the error registers, over the period of a day or
two, will log one or two errors. The system is designed to work
around these occasional errors.
Each time the master transmits a message, it expects a response
from the targeted drop. If there is no response, the master will
retransmit the message up to three more times. In these instances,
retransmitting the message will fix the momentary problem.
However, if the master has failed to receive a response after
transmitting a message four times, the drop will go offline for a
minimum of 120 ms. This indicates something is seriously wrong.
The cause of the communication failure should be investigated and
corrected before the system is allowed to continue operating.
Using the circuit shown in figure 18.3 in your ladder program will
record the fault status and enable the operator to determine that the
network has been established, the application software is running,
and the data is safe to use before restarting the system.
