50 Rockwell Automation Publication 2094-UM002E-EN-P - May 2012
Chapter 2 Planning the Kinetix 6200 and Kinetix 6500 Drive System Installation
Noise Reduction Guidelines for Drive Accessories
Refer to this section when mounting an AC (EMC) line filter or external shunt
module for guidelines designed to reduce system failures caused by excessive
electrical noise.
AC Line Filters
Observe these guidelines when mounting your AC (EMC) line filter (refer to the
figure on
page 46 for an example):
• Mount the AC line filter on the same panel as the Kinetix 6200 and
Kinetix 6500 drive and as close to the power rail as possible.
• Good HF bonding to the panel is critical. For painted panels, refer to the
examples on page 37 .
• Segregate input and output wiring as far as possible.
IMPORTANT CE test certification applies only to AC line filter and single power rail. Sharing a
line filter with multiple power rails may perform satisfactorily, but the user
takes legal responsibility.
