Aggregator Port List
Displays Link Aggregation Control information for every Aggregation Port
associated with this device.
Aggregation Port Info
Displays a list of Link Aggregation Control configuration parameters for each
Aggregation Port on this device.
Note - The current firmware version does not allow the Actor Administrative Key
and Partner Administrative System ID parameters to be configured.
Note - Device Manager does not handle 8-bit string parameters correctly. As a
result, the Actor Administrative Status and Partner Administrative Status parameters
will display unrecognizable values and will not be configurable. The Actor
Operational Status and Partner Operational Status parameters will also display
unrecognizable values.
Storm Control
Basic Info
Displays basic information about storm control.
Storm Control Protection
Displays information about the storm control protection per port.
Note - The current firmware version does not allow the following parameters to be
configured:
o
Rate Type
o
Unkown Unicast Rate
o
Unkown Multicast Rate
o
Multicast Rate
Note - Only the Broadcast Enable and Multicast Enable parameters can be
configured.
Storm Control Group
Displays information about group id for each supported frame type defined per port.
