AlliedView™-EMS 4.0.2 Device Management Guide Page 424 of 441
LED State Description
DUPLEX
Green
Orange
The port is operating in full-duplex mode.
The port is operating in half-duplex mode.
LT Green Link Test is enabled
ML Green Missing Link is enabled
SML Green Smart Missing Link is enabled
Context Menu
Note - The current firmware version returns a string of special characters as its
value for the Bootloader Version parameter.
Note - Valid MIB Set values for the Port Operation Mode parameter are "smart
missing link", "missing link" and "link test". However, the current firmware version
allows the Port Operation Mode parameter to be set to "oam bypass" or "oam
visible".
Note - The current firmware version does not allow the Port Ingress Rate Limit and
Port Egress Rate Limit parameters to be configured. Attempting to set these
parameters to valid values will result in the error message: " The error occurred
with 'Set' operation. Error: bad value.".
Note - The current firmware version returns inconsistent values on the Port
Operation Mode parameter.
AT-MCF2000 Modules
