AlliedView™-EMS 4.0.2 Device Management Guide Page 408 of 441
Converteon Series Modules
This section describes the modules supported by Device Manager. If modules are installed
on the AT-CV5000 or AT-CV1200 chassis at the time Device Manager is called, they will be
displayed in their corresponding slots on the chassis image.
•
AT-CV5M01
•
AT-CV5M02
•
AT-CM201
•
AT-CM202 and AT-CM202/x
•
AT-CM212x/1
•
AT-CM2K0S
•
AT-CM70S
•
AT-CV10x
•
AT-CV1KSS
AT-CV5M01
Management Module: 10/100TX to 100FX (100m)
AT-CV5M02
Enhanced Management Module: 10/100TX to 100FX (100m)
AT-CM201
10/100TX to 100FX (ST, 2km, MM)
LED State Description
DUP
Green
Orange
The port is operating in full-duplex mode.
The port is operating in half-duplex mode.
LT Green Link Test is enabled
SML Green Smart Missing Link is enabled
ML Green Missing Link is enabled
OAMB Green OAM Bypass is enabled
