AlliedView™-EMS 4.0.2 Device Management Guide Page 307 of 441
Device Manager LEDs for the AT-x600 Series
LED State Description
STACK ID Green
Gray
Orange
The stacked unit is either the Stacking Master or the Backup
Master.
The switch is set to standalone mode.
The stacked unit is a slave switch.
Note - Please refer to Uplink Modules for the operations and behavior of the Expansion
Modules installed on these devices.
Note - The current firmware version does not allow Device Manager to support the PWR
and RPS LEDs.
Note - The current firmware version does not allow Device Manager to detect the presence
or absence of an SFP module in any of the SFP slots. As a result, the SFP slots on the device
image and uplink module image will always show SFP images regardless of whether or not
SFP modules are physically present in the slots.
Note - The current firmware version does not allow Device Manager to detect the presence
or absence of an XFP module in any of the XFP slots. As a result, the XFP slots on the
uplink module image will always show XFP images regardless of whether or not XFP
modules are physically present in the slots.
Note - When the Spanning Tree Status parameter is set to 'enabled', the current firmware
version continues to return a value of 'forwarding' for the Port State parameter of blocking
ports. As a result, blocking ports will remain green and will not turn to yellow.
Note - Status information for combo ports will always be reflected on both the RJ-45 port
images and the SFP port images regardless of whether it is the RJ-45 or the SFP ports that
are actually in operation.
Note - The current firmware version intermittently fails to reinitialize SNMP agent once the
device is restarted. As a result, Device Manager intermittently fails to re-establish
connection with the device. To re-establish connection, user will need to re-issue the
SNMP commands from the command line interface.
Agent Menu
From the Agent menu, you can view and edit the system information for the switch, or log
into the CLI using Telnet.
