AlliedView™-EMS 4.0.2 Device Management Guide Page 180 of 441
Device Manager LEDs for AT-8600 Series
LED State Description
PWR Green
Red
The switch is receiving power from the main power supply.
Main power supply is either off or has failed.
RPS Green
Red
Gray
The switch is receiving power from the redundant power supply.
RPS has failed.
RPS is not installed or RPS monitoring is disabled.
DUPLEX Green
Orange
The port is operating at full duplex.
The port is operating at half duplex.
Note - At device start-up, the current firmware version returns 'operational' status for all
ports. As a result, RJ-45 SFP port image will appear on ports 49-50 even if there is no SFP
module inserted.
Note - The current firmware version does not allow Device Manager to support the Reset
button.
Agent Menu
From the Agent menu, you can view and edit the system information for the switch, or log
into the CLI using Telnet.
System Info
Displays basic system information, including system name, location, contact and
description.
Power Supply Info
Displays information about the power supply, redundant power supply and power
supply monitoring.
File List
Displays a list of the files in the switch's file system.
Config File Name
Displays the file name of the start-up configuration file.
Telnet
Starts a Telnet connection to the switch.
