LLDP Menu
From the LLDP menu, you can view and edit LLDP configurations, statistics, local system
data and remote systems data components.
Note
- When multiple units of the AT-x900-12X series are stacked together, port
numbering is continuous based on the Stack ID.
•
Stack ID 1 = 1 - 24
•
Stack ID 2 = 25 - 48
•
Stack ID 3 = 49 - 72
•
Stack ID 4 = 73 - 96
•
Stack ID 5 = 97 - 120
•
Stack ID 6 = 121 - 144
•
Stack ID 7 = 145 - 168
•
Stack ID 8 = 169 - 193
This numbering scheme assumes that a unit can have a maximum of 24 ports.
LLDP Configuration
General
Config
Displays LLDP general function such as enabling LLDP, transmission delays and
others.
Port
Config
Standard
Displays the LLDP configuration information of a particular port.
Note
- Device Manager does not handle objects of type BITS correctly. As a
result, the TLVs Tx Enable parameter will not be configurable and will display
an 8-bit binary string instead of the actual TLV types allowed. However, the
TLV types allowed can still be determined by looking at the bits that are on
from left to right:
•
Bit 0 - Port Description
•
Bit 1 - System Name
•
Bit 2 - System Description
•
Bit 3 - System Capabilities
Additional
Info
Displays the control selection of LLDP Port VLAN-ID TLVs (Type-Length-
Value) to be transmitted on individual ports.
Management Addresses
Displays control selection of LLDP management address TLV instances to be
transmitted.
