AlliedView™-EMS 4.0.2 Device Management Guide

Page 372 of 441

Note

- The Traffic Class Priority parameter is not applicable to AT-x900-24X series

(AlliedWare Plus) and should be ignored.

Note

- The Received Traffic Class parameter is implemented as 'read-only'.

LLDP Menu

From the LLDP menu, you can view and edit LLDP configurations, statistics, local system

data and remote systems data components.

Note

- When multiple units of the AT-x900-24X series are stacked together, port

numbering is continuous based on the Stack ID.

Stack ID 1 = 1 - 48

Stack ID 2 = 49 - 96

Stack ID 3 = 97 - 144

Stack ID 4 = 145 - 192

Stack ID 5 = 193 - 240

Stack ID 6 = 241 - 288

Stack ID 7 = 289 - 336

Stack ID 8 = 337 - 384

This numbering scheme assumes that a unit can have a maximum of 48 ports.

LLDP Configuration

General

Config

Displays LLDP general function such as enabling LLDP, transmission delays and

others.


Port

Config

Standard

Displays the LLDP configuration information of a particular port.

Note

- Device Manager does not handle objects of type BITS correctly. As a

result, the TLVs Tx Enable parameter will not be configurable and will display

an 8-bit binary string instead of the actual TLV types allowed. However, the

TLV types allowed can still be determined by looking at the bits that are on

from left to right:

Bit 0 - Port Description

Bit 1 - System Name

Bit 2 - System Description

Bit 3 - System Capabilities
