AlliedView™-EMS 4.0.2 Device Management Guide

Page 266 of 441

AT-9748TS/XP

(With 10G Uplink)

AT-9748TS/XP

(No Uplink)

AT-9724TS

2

4

<=2

2

3

<=4

2

2

<=6

2

1

<=8

2

0

<=10

1

6

<=1

1

5

<=3

1

4

<=5

1

3

<=7

1

2

<=9

1

1

<=10

1

0

<=11

0

7

<=2

0

6

<=4

0

5

<=6

0

4

<=8

0

3

<=9

0

2

<=10

0

1

<=11


Device Manager LEDs for AT-9700 Series

LED

State

Description

PWR

Green The switch is receiving power from the main power supply.

RPS Green

Gray

The switch is receiving power from the redundant power supply.

RPS is not installed or not functioning.

STACK

ID

Green

Orange

The stacked unit is either a slave switch or the switch is not in a

stacked mode.

The stacked unit is the master switch.

DUPLEX Green

Orange

The port is operating in full-duplex mode.

The port is operating in half-duplex mode.

Note

- The Stack ID LED indicates the Box ID of the stacked switch or standalone switch.
