AlliedWare Plus Version 2.1.8 Management Software Web Interface User’s Guide
99
5. Select a port number with the Port Number pull-down menu.
You can only assign one port number to a unicast MAC address.
6. Select a VLAN with the VLAN pull-down menu.
For a unicast address, this field specifies the name of the VLAN where
the node designated by the MAC address is a member.
7. Click Add.
8. Click SAVE.
Assigning a
Multicast
Address
To assign a multicast MAC address to the MAC address table, do the
following:
1. Hover the cursor over the Switching tab.
The Switching tab is displayed. See Figure 20 on page 59.
2. Hover over Mac Table and then move the cursor to the right to select
Multicast.
The Multicast MACs Page is displayed. See Figure 35 on page 97.
3. Click Add.
The Add Multicast Mac Address Page is displayed. See Figure 37.
Figure 37. Add Multicast Mac Address Page
