AlliedWare Plus Version 2.1.8 Management Software Web Interface User’s Guide
231
Displaying LLDP Neighbor Information
To display LLDP Neighbor Information, use the following procedures:
 “Displaying LLDP Neighbor Information”
 “Displaying LLDP Neighbor Detail” on page 232
Displaying LLDP
Neighbor
Information
To display LLDP Neighbor information, do the following:
1. Hover the cursor over the Discovery & Monitoring tab.
The Discovery & Monitoring tab is displayed. See Figure 73 on page
211.
2. From the Discovery & Monitoring tab, hover over LLDP, move the
cursor to the right, and then select Neighbors.
The LLDP Neighbors Information page is displayed. See Figure 91.
Figure 91. LLDP Neighbors Information Page
The following fields are displayed:
 Local Port— Port number.
 Neighbor Chassis ID— ID number of the neighbor’s chassis.
 Neighbor Port Name— The neighbor’s port number that sent the
information.
 Neighbor System Name— Neighbor’s system name.
