AlliedWare Plus Version 2.1.8 Management Software Web Interface User’s Guide
149
Displaying Switch Spanning Tree Protocol Settings
To display the switch Spanning Tree Protocol settings do the following:
1. Hover the cursor over the Switching tab.
The Switching tab is displayed. See Figure 20 on page 59.
2. From the Switching tab drop-down menu, select Spanning Tree.
The Spanning Tree Settings page is displayed. See Figure 54.
Figure 54. Spanning Tree Settings Page
The following fields are displayed:
 Active Protocol— Indicates if the active spanning tree protocol is
STP or RSTP. The default setting is RSTP.
 Status— Indicates if the spanning tree protocol is enabled or
disabled on the switch.
 Current Priority— By default, the current priority is set to 32,768.
You cannot change this field.
 New Priority (0-15)— Switch priority number. The device that has
the lowest priority number in the spanning tree domain becomes
the root bridge. If two or more devices have the same priority
value, the device with the numerically lowest MAC address
becomes the root bridge.
