AlliedWare Plus Version 2.1.8 Management Software Web Interface User’s Guide
201
3. Click the box next to the Static IP Address field. This is the default
setting.
4. Assign a VLAN to the IPv4 address by using the pull-down menu next
to the Interface Name field.
You can only select a VLAN that you have configured previously. For
information about how to assign a VLAN, see Chapter 11, “Setting
Port-based and Tagged VLANs” on page 125.
5. Enter an IPv4 address in the IP Address field in the following format:
xxx.xxx.xxx.xxx
where xxx is a number from 0 to 255. There are four groups of
numbers that are separated by periods.
6. Enter a value in the Net Mask field to assign a subnet mask to the
switch.
The Next Mask is a decimal number that represents the number of bits,
from left to right, that constitute the network portion of the address. For
example:
 The decimal mask 16 is equivalent to the mask 255.255.0.0.
 The decimal mask 24 is equivalent to the mask 255.255.255.0.
7. To assign a default gateway to the switch, enter an IPv4 address in the
Default IP Gateway field.
The IPv4 address is specified in the following format:
xxx.xxx.xxx.xxx
where xxx is a number from 0 to 255. There are four groups of
numbers that are separated by periods.
For more information about the default gateway, see “IP Management
Guidelines” on page 199.
8. Click Apply.
9. Click SAVE.
Assigning a
DHCP IPv4
Address
Use this procedure to assign the switch an IPv4 management address
from a DHCP server. This procedure activates the DHCP client, which
automatically queries the network for a DHCP server. The client also
queries for a DHCP server whenever you reset or power-cycle the switch.
