Chapter 14: Power Over Ethernet (PoE)
160
PoE Configuration
You can specify global PoE settings on all ports on the switch using the
PoE page - refer to “Configuring Global PoE Settings”. You can also
specify PoE settings on individual ports using the Modify Port PoE
Settings page - refer to “Configuring Individual Port PoE Settings” on
page 160.
Configuring
Global PoE
Settings
To configure global PoE settings on all ports on the switch, do the
following:
1. Hover the cursor over the Switching tab.
The Switching tab is displayed. See Figure 20 on page 59.
2. From the Switching tab drop-down menu, select PoE.
The PoE page is displayed. See Figure 55 on page 158.
3. From the Status menu, select Enabled or Disabled:
 Enabled enables PoE on all ports on the switch.
 Disabled disables PoE on all ports on the switch.
4. Click Apply.
5. In the Power Usage Threshold field, enter the threshold of the switch’s
total available system and PoE power. The range is 1 to 99%.
6. Click Apply.
7. Click SAVE.
Configuring
Individual Port
PoE Settings
To configure global PoE settings on individual ports on the switch, do the
following:
1. Hover the cursor over the Switching tab.
The Switching tab is displayed. See Figure 20 on page 59.
2. From the Switching tab drop-down menu, select PoE.
The PoE page is displayed. See Figure 55 on page 158.
3. Select Edit next to the port you want to modify.
The Modify Port PoE Settings page is displayed. See Figure 56 on
page 161.
