Chapter 19: Setting LLDP and LLDP-MED
220
4. Define or edit the following fields as needed:
 Status— Choose whether LLDP is enabled or disabled on the
switch. By default, LLDP is disabled on the switch.
 Timer— Transmit interval. The range is 5 to 32,768 seconds. The
default value is 30 seconds.
 Fast Start Count— Fast-start count for LLDP-MED. The fast-start
count determines how many fast-start advertisements LLDP sends
from a port when it begins sending LLDP-MED advertisements
from a port, for instance when it detects a new LLDP-MED capable
device. The range is 1 to 10. The default value is 3.
 Holdtime Multiplier— Holdtime multiplier value. The transmit
interval is multiplied by the holdtime multiplier to give the Time To
Live (TTL) the switch advertises to the neighbors. The range is 2 to
10. The default value is 4.
 Non Strict Med TLV Order Check— Sets the switch to accept
LLDP-MED advertisements, even if the TLVs are not in the
standard order, as specified in ANSI/TIA-1057. This configuration
is useful if the switch is connected to devices that send LLDP-MED
advertisements in which the TLVs are not in the standard order.
Click in the box next to this field to select the nonstrict Med TLV
Order Check.
 Notification Interval— Notification interval. This is the minimum
interval between LLDP SNMP notifications (traps). The range is 5
to 3,600 seconds. The default value is 5.
 Reinit— Reinitialization delay. This is the number of seconds that
must elapse after LLDP is disabled on a port before it can be
reinitialized. The range is 1 to 10 seconds. The default value is 2.
 Tx Delay— Transmission delay. This is the minimum time interval
between transmissions of advertisements due to changes in LLDP
local information. The range is 1 to 8192 seconds. The default
value is 2.
 Total Neighbors— Indicates the number of LLDP neighbors the
switch has discovered on all its ports. You cannot modify this field.
 Neighbors Last Update— Indicates the time since the LLDP
neighbor table was last updated. You cannot modify this field.
5. Click Apply.
6. Click SAVE.
Setting LLDP
Port Assignments
To assign LLDP to a port, do the following:
1. Hover the cursor over the Discovery & Monitoring tab.
The Discovery & Monitoring tab is displayed. See Figure 73 on page
211.
