Allied Telesis AT-9000 Series - Manual (Page 98)

Chapter 8: Setting the MAC Address
98
Assigning a MAC Address
You can assign a new unicast or multicast MAC address to the MAC
address table. See the following procedures:
 “Assigning a Unicast Address”
 “Assigning a Multicast Address” on page 99
Assigning a
Unicast Address
To assign a unicast MAC address to the MAC address table, do the
following:
1. Hover the cursor over the Switching tab.
The Switching tab is displayed. See Figure 20 on page 59.
2. Hover over Mac Table and then move the cursor to the right to select
Unicast.
The Unicast MACs page is displayed. See Figure 34 on page 96.
3. Click Add.
The Add Unicast Mac Address Page is displayed. See Figure 36.
Figure 36. Add Unicast Mac Address Page
4. Enter a unicast MAC address in the Mac Address field. Use the
following format: xx:xx:xx:xx:xx:xx or xxxx.xxxx.xxxx
