Allied Telesis AT-9000 Series - Manual (Page 132)

Chapter 11: Setting Port-based and Tagged VLANs
132
Modifying VLANs
To modify the VLAN settings, do the following:
1. Hover the cursor over the Switching tab.
The Switching tab is displayed. See Figure 20 on page 59.
2. From the Switching tab drop-down menu, select Virtual LANs.
The VLANs page is displayed. See Figure 47 on page 128.
3. From the VLANs page, click Edit next to the VLAN ID that you want to
modify.
The Modify VLAN page is displayed. See Figure 49.
Figure 49. Modify VLAN Page
Note
The VLAN ID specifies a VLAN identifier. The range is 2 to 4094.
The VID 1 is reserved for the Default_VLAN. The VID cannot be the
same as the VID of an existing VLAN on the switch. If this VLAN is
unique in your network, its VID must also be unique. However, if this
VLAN is part of a larger VLAN that spans multiple switches, the VID
value for the VLAN must be the same on each switch.
