Displaying System Information
To view basic information about the switch, do the following:
1. Hover the cursor over the System Tab.
2. From the drop-down menu, click Dashboard.
The Dashboard Page is displayed. See Figure 4 on page 23.
The following fields are displayed:
 Up Time— Length of time since the switch was last reset or power
cycled in days, hours, minutes and seconds.
The System section displays the following information:
 Software Version— Software version number of the AlliedWare
Plus software.
 Build Date/Time— Month, date, year and time (in the
hour:minute:second format) the software version was built.
 Serial No.— Unique serial number of the switch.
 MAC Address— MAC address of the switch.
 IPv4 Address— IPv4 management address assigned to the switch
and subnet mask of the web interface. The address is specified in
the following format:
xxx.xxx.xxx.xxx
Each “xxx” is a decimal number from 0 to 255. The numbers must
be separated by periods.
Note
For both the IPv4 and IPv6 addresses, the subnet mask is a decimal
number that represents the number of bits, from left to right, that
constitute the network portion of the address. Here are some
examples:
— The decimal mask 16 is equivalent to the mask 255.255.0.0.
— The decimal mask 24 is equivalent to the mask 255.255.255.0
— The IPv6 decimal mask 24 is equivalent to the mask
FFFF:FF00::0.
 IPv4 Gateway— IPv4 address of the next hop of the switch’s
default route. The switch uses a default route to reach a remote
subnet.
 System Name— Name of the switch. To configure this field, see
“Setting the Switch Information” on page 40.
