UWBTracer/Trainer User Manual

Chapter 4: Reading Traces

LeCroy Corporation

51

WUSB Packet Level

Click the WUSB PKT button to show the WUSB Packet Level view. An example packet
level is in Figure 4.4.

Figure 4.4 Trace View: WUSB Packet Level

The WUSB Packet Level is now a special way to decode the Frame Level. You can show
or hide MAC Frame raw payload PHY/MAC headers when WUSB Packets are displayed.
You cannot expand WUSB packets.

WUSB Transaction Level

Click the USB TRA button to show the WUSB Transaction Level view. An example
transaction level is in Figure 4.5.

Figure 4.5 Trace View: WUSB Transaction Level
