Chapter 3: Software Overview UWBTracer/Trainer User Manual
34
LeCroy Corporation
Step 3 The Edit Marker for Frame # dialog box appears (Figure 3.13).
Figure 3.13 Edit Marker for Frame Dialog Box
Step 4 Enter your comment.
Step 5 Click OK.
Step 6 A marked frame is indicated by a vertical red bar along the left edge of
the Frame # block (left side of Figure 3.14).
Figure 3.14 A Marked Frame
