UWBTracer/Trainer User Manual Chapter 3: Software Overview
LeCroy Corporation
25
View
Toolbars Displays list of available Tool bars.
Analyzer Network
Chat Bar
Opens a dialog that allows users to conduct chat sessions over an IP
LAN. In order to send and receive electronic text messages, each user
must be working with a PC that is on an IP LAN and also attached to an
analyzer.
Status Bar Switches display of the Status Bar ON or OFF.
Hide Traffic on
Channels Hides traffic on the channel (MPI or RF) selected from the popup list.
Hide Dec/Orig
Traffic Hides Decrypted or Original traffic, as selected from the popup list.
Hide Frame Types Hides Beacon, Control, Command, Data, and/or Agg Data frames.
Hide Reserved
Field Warnings Hides fields that have a Reserved Field Warning.
Unhide Cells Unhides the cells (hidden by Display Options) selected from the popup
list.
Zoom In Increases the size of the displayed elements.
Zoom Out Decreases the size of the displayed elements.
Wrap Wraps displayed Frames within the window.
Apply Decoding
Scripts
Decoding scripts set the values of the display and recording options for
optimum views of trace information from specific vendors or classes of
data. The menu allows you to select the vendor or class of data for the
request recipients and endpoints listed in the Request Recipients and
Endpoints menu. You can keep the settings across recordings.
Real-Time Statistics Displays trace statistics.
Window
New Window Opens another instance of the Main Window.
Cascade Displays all open Main windows in cascaded format.
Tile Horizontal Displays all open Main windows in tiled horizontal format.
Tile Vertical Displays all open Main windows in tiled vertical format.
Arrange Icons Arranges Main window icons at bottom of display area.
Windows Displays a list of open windows.
Menu/Option Function
