Teledyne LeCroy UWBTracer User Manual User Manual
Page 181
UWBTracer/Trainer User Manual
Chapter 10: Connecting to Analyzers
LeCroy Corporation
163
Figure 10.8 shows how to connect two analyzers in a ring network for synchronized
recording.
Figure 10.8 Connecting Two Analyzers for Synchronized Recording
Figure 10.9 shows how to connect three analyzers in a ring network for synchronized
recording.
Figure 10.9 Connecting Three Analyzers for Synchronized Recording
