UWBTracer/Trainer User Manual Appendix A: MPI
LeCroy Corporation
289
Table A.2 Adapter Pin Assignments: 60-Pin Probe Cable
Pin Definition Pin Definition
1 CCA_STATUS 2 Reserved
3 Reserved 4 SERIAL_DATA
5 PCLK 6 DGND
7 PHY_RESET 8 PHY_TX_EN
9 SLEEP 10 +3.3V
11 DATA[0] 12 PHY_RX_EN
13 DATA[2] 14 DGND
15 DGND 16 DATA_EN
17 DATA[4] 18 DATA[1]
19 DATA[6] 20 DATA[3]
21 +3.3V 22 DATA[5]
23 PHY_ACTIVE 24 DATA[7]
25 Reserved 26 DGND
27 NA 28 NA
29 NA 30 NA
31 NA 32 DGND
33 NA 34 +3.3V
35 NA 36 NA
37 NA 38 NA
39 NA 40 NA
41 NA 42 NA
43 DGND 44 NA
45 +3.3V 46 NA
47 NA 48 NA
49 NA 50 NA
51 +3.3V 52 DGND
53 Reserved 54 NA
55 Reserved 56 NA
57 DGND 58 Reserved
59 NA 60 NA
