UWBTracer/Trainer User Manual Chapter 9: Reports
LeCroy Corporation
111
Traffic Summary Buttons
The Traffic Summary toolbar provides a shortcut to commands that control the traffic
summary (Figure 9.6).
Figure 9.6 Traffic Summary Toolbar
Table 9.1 describes the Traffic Summary buttons.
Table 9.1Traffic Summary Buttons
Using the Traffic Summary
To use the traffic summary window, you need to know how to select the items for which
you want a summary, to set a range for the summary, and to use navigational features.
Save. Saves the traffic summary to
a file in HTML format. Text. Displays the traffic summary in
text format.
Email/Send. Sends the traffic
summary in HTML format via an
email. Options/View. Opens a menu that
allows you to set the way trace file
items are counted for the traffic
summary.
Print. Prints the traffic summary.
Select Range. Sets a range of items
to be counted in the trace file.
