2.9.4 Trace Properties
Select File > Trace Properties to see the properties of the trace. For more information refer
to
“Trace Properties” on page 115 .
2.9.5 Edit Comment
You can write comments and edit them for a trace for future use. Select File > Edit
Comment to view the edit window. Key in the comments and close the window.
2.10 Projects
You can define a new project, starting with the default project definition, or modify the
settings for the last project run.
New Default Project
To start a New project, select File > New on the main menu bar and choose
Protocol Analyzer to open a new project with default settings that you can modify
(see
“Main Window” on page 37 ).
Last Project
Clicking the Green button opens the last project run, so you can modify it.
2.10.1 Project File Types
Projects have the following file types:
*.asl Decoding script file (in the Examples folder “User Define Decoding Script”
subfolder)
*.cfg Display Configuration file (in the System folder “Config” subfolder)
*.dat DataBlock file (in the System folder “DataBlock” subfolder)
*.sac SAS Protocol Analyzer/Capture Project/Viewer file (in the Examples folder
“EasyCaptr”, “AdvanceCaptr”, or “Exerciser” subfolders)
*.saf Device Identifier file
*.scs SAS Sample file (in the SAS Examples folder “Sample” subfolder)
*.sfl Filter configuration file
*.spg Single‐role Pattern Generator file (in the Examples folder
SAS “PatternGenerator\Single role (spg files)” subfolder and
SATA “PatternGenerator\Single Role” subfolder). Single role means the file is
for a Device or Host.
*.ssh SAS Search configuration File
*.stc SATA Protocol Analyzer/Capture Project/Viewer file (in the Examples folder
“EasyCaptr”, “AdvanceCaptr”, or “Exerciser” subfolders)
