Navigation + View Toolbar
172
Sierra M6‐1 SAS/SATA Protocol Analyzer User Manual
Bus Condition
When selected, depending on the Filter Type, the Hide/Show selection shows or hides
captured Bus Conditions in the Trace Viewer.
Incomplete Frames
When selected, depending on the Filter Type, the Hide/Show selection shows or hides
Incomplete Frames in the Trace Viewer.
FIS
When selected, depending on the Filter Type, the Hide/Show selection shows or hides
captured FIS items in the Trace Viewer.
ATA Command
When selected, depending on the Filter Type, the Hide/Show selection shows or hides
captured ATA commands in the Trace Viewer.
Protocol Error
When selected, depending on the Filter Type, the Hide/Show selection shows or hides
captured packets with the specified Protocol Errors in the Trace Viewer.
Port
When selected, depending on the Filter Type, the Show/Hide selection shows or hides
packet traffic for the selected port.
ATAPI SCSI Command
When selected, depending on the Filter Type, the Show/Hide selection shows or hides
ATAPI SCSI commands.
Miscellaneous
When you choose Miscellaneous, an additional dialog displays, allowing you to specify
the filtering of State Range and/or External Signal In (see
).
3.5.6
Enable Filter
Select Filtering > Enable Filtering or click the
Filter Enable button on the display
menu bar to toggle between Filtered and Unfiltered display.
3.5.7
Filter Idle
Depending on the Filter Type (Hide/Show), Idle packets in the Sample Viewer are shown
or hidden.
You can quickly filter idles by clicking the
Filter Idle button. This button toggles
between Show and Hide items.
