HomeSafe User’s Guide
LAN Screens 5-7
Table 5-2 LAN : Static DHCP
LABEL DESCRIPTION
# This is the index number of the Static IP table entry (row).
MAC Address Type the MAC address (with colons) of a computer on your LAN.
IP Address This field specifies the size, or count of the IP address pool.
Apply Click Apply to save your changes back to the HomeSafe.
Reset Click Reset to begin configuring this screen afresh.
5.7 Configuring IP Alias
IP Alias allows you to partition a physical network into different logical networks over the same
Ethernet interface. The HomeSafe supports three logical LAN interfaces via its single physical
Ethernet interface with the HomeSafe itself as the gateway for each LAN network.
To change your HomeSafe’s IP Alias settings, click LAN, then the IP Alias tab. The screen
appears as shown.
Figure 5-4 LAN : IP Alias
The following table describes the labels in this screen.
Table 5-3 LAN : IP Alias
LABEL DESCRIPTION
IP Alias 1,2 Select the check box to configure another LAN network for the HomeSafe.
IP Address Enter the IP address of your HomeSafe in dotted decimal notation.
IP Subnet Mask Your HomeSafe will automatically calculate the subnet mask based on the IP
address that you assign. Unless you are implementing subnetting, use the subnet
mask computed by the HomeSafe.
