HomeSafe User’s Guide
Remote Node Configuration 22-7
Use menu 11.5 to specify the filter set(s) to apply to the incoming and outgoing traffic between
this remote node and the HomeSafe to prevent certain packets from triggering calls. You can
specify up to 4 filter sets separated by commas, for example, 1, 5, 9, 12, in each filter field. Note
that spaces are accepted in this field. For more information on defining the filters, please refer to
the Filters chapter. For PPPoE or PPTP encapsulation, you have the additional option of
specifying remote node call filter sets.
Figure 22-5 Menu 11.5: Remote Node Filter (Ethernet Encapsulation)
Figure 22-6 Menu 11.5: Remote Node Filter (PPPoE or PPTP Encapsulation)
22.4.1 Traffic Redirect Setup
Configure parameters that determine when the HomeSafe will forward WAN traffic to the backup
gateway using Menu 11.6 — Traffic Redirect Setup.
Figure 22-7 Menu 11.6: Traffic Redirect Setup
The following table describes the fields in this screen.
Menu 11.5 - Remote Node Filter
Input Filter Sets:
protocol filters=
device filters=
Output Filter Sets:
protocol filters=
device filters=
Call Filter Sets:
protocol filters=
device filters=
Enter here to CONFIRM or ESC to CANCEL:
Menu 11.5 - Remote Node Filter
Input Filter Sets:
protocol filters=
device filters=
Output Filter Sets:
protocol filters=
device filters=
Enter here to CONFIRM or ESC to CANCEL:
Menu 11.6 - Traffic Redirect Setup
Active= Yes
Configuration:
Backup Gateway IP Address= 0.0.0.0
Metric= 14
Check WAN IP Address= 0.0.0.0
Fail Tolerance= 2
Period(sec)= 5
Timeout(sec)= 3
Press ENTER to Confirm or ESC to Cancel:
