HomeSafe User’s Guide
22-4 Remote Node Configuration
Table 22-2 Fields in Menu 11.1 (PPPoE Encapsulation Specific)
FIELD DESCRIPTION EXAMPLE
Service Name If you are using PPPoE encapsulation, then type the name of your
PPPoE service here. Only valid with PPPoE encapsulation. poellc
Authen This field sets the authentication protocol used for outgoing calls.
Options for this field are:
CHAP/PAP - Your HomeSafe will accept either CHAP or PAP when
requested by this remote node.
CHAP - accept CHAP only.
PAP - accept PAP only.
CHAP/PAP
Telco Option
Allocated
Budget
The field sets a ceiling for outgoing call time for this remote node. The
default for this field is 0 meaning no budget control. 0
(default)
Period(hr) This field is the time period that the budget should be reset. For
example, if we are allowed to call this remote node for a maximum of 10
minutes every hour, then the Allocated Budget is (10 minutes) and the
Period(hr) is 1 (hour).
0
(default)
Schedules You can apply up to four schedule sets here. For more details please
refer to the Call Schedule Setup chapter.
Nailed-Up
Connection
This field specifies if you want to make the connection to this remote
node a nailed-up connection. More details are given earlier in this
section. No
(default)
Session
Options
Idle Timeout Type the length of idle time (when there is no traffic from the HomeSafe
to the remote node) in seconds that can elapse before the HomeSafe
automatically disconnects the PPPoE connection. This option only
applies when the HomeSafe initiates the call.
100 seconds
(default)
22.2.3 PPTP Encapsulation
If you change the Encapsulation to PPTP in menu 11.1, then you will see the next screen. Please
see the appendix for information on PPTP.
Figure 22-3 Menu 11.1 Remote Node Profile for PPTP Encapsulation
The next table shows how to configure fields in menu 11.1 not previously discussed.
Menu 11.1 - Remote Node Profile
Rem Node Name= Route=
Active=
Apply Alias=
Encapsulation= Edit IP=
Service Type= Telco Option:
Service Name= N/A Allocated Budget(min)=
Outgoing: Period(hr)=
My Login= Schedules=
My Password= Nailed-Up Connection=
Retype to Confirm=
Authen=
PPTP My IP: Session Options:
My IP Addr= Edit Filter Sets=
My IP Mask= Idle Timeout(sec)=
Server IP Addr=
Connection ID/Name= Edit Traffic Redirect=
Press ENTER to Confirm or ESC to Cancel:
