HomeSafe User’s Guide
NAT 25-5
Table 25-3 Menu 15.1.1 First Set
FIELD DESRIPTION EXAMPLE
Set Name Enter a name for this set of rules. This is a required field. If this field
is left blank, the entire set will be deleted. NAT_SET
Action The default is Edit. Edit means you want to edit a selected rule (see
following field). Insert Before means to insert a rule before the rule
selected. The rules after the selected rule will then be moved down
by one rule. Delete means to delete the selected rule and then all the
rules after the selected one will be advanced one rule. None disables
the Select Rule item. Edit
Select Rule When you choose Edit, Insert Before or Delete in the previous field
the cursor jumps to this field to allow you to select the rule to apply
the action in question. 1
)
You must press [ENTER] at the bottom of the screen to save the
whole set. You must do this again if you make any changes to the set
– including deleting a rule. No changes to the set take place until this
action is taken.
Selecting Edit in the Action field and then selecting a rule brings up the following menu, Menu
15.1.1.1
- Address Mapping Rule in which you can edit an individual rule and configure the
Type, Local and Global Start/End IPs.
)
An End IP address must be numerically greater than its
corresponding IP Start address.
Figure 25-7 Menu 15.1.1.1 Editing/Configuring an Individual Rule in a Set
The following table explains the fields in this menu.
Table 25-4 Menu 15.1.1.1 Editing/Configuring an Individual Rule in a Set
FIELD DESCRIPTION EXAMPLE
Type Press [SPACE BAR] and then [ENTER] to select from a total of five
types. These are the mapping types discussed in the chapter on NAT
web configurator screens. Server allows you to specify multiple servers
of different types behind NAT to this computer. See section 25.5.3 for an
example. One-to-One
Local IP Only local IP fields are N/A for server; Global IP fields MUST be set for
Menu 15.1.1.1 Address Mapping Rule
Type= One-to-One
Local IP:
Start= 0.0.0.0
End = N/A
Global IP:
Start= 0.0.0.0
End = N/A
Press ENTER to Confirm or ESC to Cancel:
