HomeSafe User’s Guide
Call Scheduling 34-1
Chapter 34
Call Scheduling
Call scheduling (applicable for PPPoA or PPPoE encapsulation only) allows you to
dictate when a remote node should be called and for how long.
34.1 Introduction to Call Scheduling
The call scheduling feature allows the HomeSafe to manage a remote node and dictate when a
remote node should be called and for how long. This feature is similar to the scheduler in a
videocassette recorder (you can specify a time period for the VCR to record). You can apply up to
4 schedule sets in Menu 11.1 — Remote Node Profile. From the main menu, enter 26 to access
Menu 26 — Schedule Setup as shown next.
Figure 34-1 Menu 26 Schedule Setup
Lower numbered sets take precedence over higher numbered sets thereby avoiding scheduling
conflicts. For example, if sets 1, 2 ,3 and 4 in are applied in the remote node then set 1 will take
precedence over set 2, 3 and 4 as the HomeSafe, by default, applies the lowest numbered set first.
Set 2 will take precedence over set 3 and 4, and so on.
You can design up to 12 schedule sets but you can only apply up to four schedule sets for a
remote node.
)
To delete a schedule set, enter the set number and press [SPACE
BAR] and then [ENTER] (or delete) in the Edit Name field.
To setup a schedule set, select the schedule set you want to setup from menu 26 (1-12) and press
[ENTER] to see Menu 26.1 — Schedule Set Setup as shown next.
Menu 26 - Schedule Setup
Schedule Schedule
Set # Name Set # Name
------ ----------------- ------ -----------------
1 _______________ 7 _______________
2 _______________ 8 _______________
3 _______________ 9 _______________
4 _______________ 10 _______________
5 _______________ 11 _______________
6 _______________ 12 _______________
Enter Schedule Set Number to Configure= 0
Edit Name= N/A
Press ENTER to Confirm or ESC to Cancel:
