HomeSafe User’s Guide
25-12 NAT
Figure 25-20 Example 4: Menu 15.1.1 Address Mapping Rules
25.6 Configuring Trigger Port Forwarding
)
Only one LAN computer can use a trigger port (range) at a time.
Enter 3 in menu 15 to display Menu 15.3 — Trigger Port Setup, shown next.
Figure 25-21 Menu 15.3 Trigger Port Setup
The following table describes the fields in this screen.
Menu 15.1.1 - Address Mapping Rules
Set Name= Example4
Idx Local Start IP Local End IP Global Start IP Global End IP Type
--- --------------- --------------- --------------- --------------- ------
1. 192.168.1.10 192.168.1.12 10.132.50.1 10.132.50.3 M:M NO OV
2.
3.
4.
5.
6.
7.
8.
9.
10.
Action= Edit Select Rule=
Press ENTER to Confirm or ESC to Cancel:
Menu 15.3 - Trigger Port Setup
Incoming Trigger
Rule Name Start Port End Port Start Port End Port
----------------------------------------------------------------------
1. Real Audio 6970 7170 7070 7070
2. 0 0 0 0
3. 0 0 0 0
4. 0 0 0 0
5. 0 0 0 0
6. 0 0 0 0
7. 0 0 0 0
8. 0 0 0 0
9. 0 0 0 0
10. 0 0 0 0
11. 0 0 0 0
12. 0 0 0 0
Press ENTER to Confirm or ESC to Cancel:
