HomeSafe User’s Guide
System Information and Diagnosis 30-1
Chapter 30
System Information and Diagnosis
This chapter covers the information and diagnostic tools in SMT menus 24.1 to 24.4.
These tools include updates on system status, port status, log and trace capabilities and upgrades
for the system software. This chapter describes how to use these tools in detail.
Type 24 in the main menu to open Menu 24 – System Maintenance, as shown in the following
figure.
Figure 30-1 Menu 24 System Maintenance
30.1 System Status
The first selection, System Status gives you information on the status and statistics of the ports, as
shown next Figure 30-2. System Status is a tool that can be used to monitor your HomeSafe.
Specifically, it gives you information on your ADSL telephone line status, number of packets sent
and received.
To get to System Status, type 24 to go to Menu 24 — System Maintenance. From this menu,
type 1. System Status. There are two commands in Menu 24.1 — System Maintenance —
Status. Entering 1 resets the counters; [ESC] takes you back to the previous screen.
The following table describes the fields present in Menu 24.1 — System Maintenance — Status
which are read-only and meant for diagnostic purposes.
Menu 24 - System Maintenance
1. System Status
2. System Information and Console Port Speed
3. Log and Trace
4. Diagnostic
5. Backup Configuration
6. Restore Configuration
7. Upload Firmware
8. Command Interpreter Mode
9. Call Control
10. Time and Date Setting
11. Remote Management Setup
